Taidacent RS485 Modbus Soil Water Potential Sensor Soil Moisture Tension Sensor Soil Water Tension Land Agricultural Irrigation

Soil water potential refers to the work (energy required) done by transferring a unit amount of pure water from a standard state (usually a pure water pool with a pressure of one atmosphere, a temperature of 25°C, and at the same height as the soil water) to a certain point in the soil under isothermal and isobaric conditions. Our company's soil water potential sensor is a professional device designed specifically for measuring soil water potential. The sensor uses advanced sensing technology to establish energy balance with soil moisture through built-in sensitive elements. When the soil water potential changes, the sensitive element will sense the corresponding pressure or tension changes. It can monitor the energy state of soil moisture in real time, present the effectiveness of soil moisture in the form of intuitive data, help users accurately grasp the soil moisture status, and provide key data support for scientific irrigation, agricultural production management, and ecological environment research.

• Soil water potential refers to the work (energy required) done by transferring a unit amount of pure water from a standard state (usually a pure water pool with a pressure of one atmosphere, a temperature of 25°C, and at the same height as the soil water) to a certain point in the soil under isothermal and isobaric conditions.
• Our company's soil water potential sensor is a professional device designed specifically for measuring soil water potential. The sensor uses advanced sensing technology to establish energy balance with soil moisture through built-in sensitive elements. When the soil water potential changes, the sensitive element will sense the corresponding pressure or tension changes.
• It can monitor the energy state of soil moisture in real time, present the effectiveness of soil moisture in the form of intuitive data, help users accurately grasp the soil moisture status, and provide key data support for scientific irrigation, agricultural production management, and ecological environment research.
• Accuracy 10% Operating Temperature -40℃~+60℃ Voltage - Supply 5V to 30V DC Max power consumption 0.25W at DC12V Range -5 to 100KPA Resultion 0.1kpa Waterproof IP68
• Drilling or digging a hole or pit: Use an auger or shovel to dig a hole or pit of appropriate depth at the selected location, and the depth must reach the planned sensor installation depth. Processing the sensor: Add water to the collected in-situ soil to make mud or directly moisten the soil. Wrap the sensor with wet soil or mud and insert it into the dug hole or pit; if it is installed at a deeper location, slowly put the sensor into the hole or pit, and then slowly pour the prepared mud into the hole or pit, so that the sensor measurement part and the soil are fully in contact.
